3.5 Anaesthesia System Switch
The system swtch (1) controls the operaton of the anaesthetc
machne
Swtch labellng
I ndcates On
0 ndcates Off
Electrcal power supply
The system swtch controls the electrcal supply to the
Ventlator nterface crcut, and the Electronc Flow Dsplay
Pneumatc functon
The system swtch controls the oxygen supply and must be
n the ‘On’ poston for normal operaton of the anaesthetc
machne
NOTE
The oxygen supply falure warnng whstle sounds for a
mnmum of seven seconds when there s a reducton of
oxygen supply pressure
3.6 Pressure Gauges
Pressure gauges (50 mm dameter) are located on the front
panel (1)
The gauges are colour coded and labelled
The gauge for Ar s postoned between Oxygen and Ntrous
Oxde
Unused gauge postons are blanked out
The gauges are calbrated n kPa x 100
