Specification
4.9 Ventilator
Applcaton Ventlaton of adult, paedatrc and neonatal patents for use n anaesthesa
WARNIN
Neonates Do not use volume mode for neonates
Use ONLY pressure control ventlaton (pressure mode) for mandatory ventlaton of
neonates
Modes VCV, PCV, SIMV, SIMV, PSV, PRVC
Internal omplance
Adult bellows
Paedatrc bellows
3 ml/cmHO (nomnal)
2 ml/cmHO (nomnal)
Physcal
Bellows
Adult
Paedatrc
(Note - bellows are latex free)
20 - 1600 ml
20 - 350 ml
Battery Back-up 12 V, 4 Ah, sealed lead-acd battery
Fully charged battery provdes 75 mnutes (nomnal) backup
Drve as Oxygen at 280 to 600 kPa (41 to 87 ps)
Alarms
Alarm Mute 30 or 120 seconds
Apnoea Flow referenced (no breath detected wthn 15 seconds)
Hgh ontnuous Arway Pressure PEEP + 10 cmHO for 1 cycle, or PEEP + 5 cmHO for 3 cycles
A PEEP value of 4 cmHO s used for PEEP values ≤4 cmHO
Standby Mode the alarm trggers after 15 seconds
Low Pressure (Pressure ontrol) Bellows drve gas pressure sensor fals to detect at least 75% of set target level
Incorrect Rate or Rato Ventlator parameter settngs unachevable
Mans Falure Fully charged battery provdes 75 mnutes (nomnal) backup
Low Battery If the machne s runnng on battery power, less than 20 mnutes battery lfe
remans
Ventlator Inoperatve Internal falure
Outlet Blocked Exhaust valve outlet blocked
Alarms - User Adustable
Low Tdal Volume Measured value s below 50% of volume set Range 10 - 1600 ml
Hgh Tdal Volume Measured value exceeds 150% of volume set Range 20 - 2400 ml
Low Mnute Volume alculated value s 50% below volume set Range 0 - 50 L
Hgh Mnute Volume alculated value exceeds 150% of volume set Range 1 - 75 L
Low and Hgh O oncentraton 18% - 105%
Hgh Arway Pressure 10 - 80 cmHO adustable
Functonal
Tdal Volume Range
Adult bellows
Paedatrc bellows
20 to 1600 ml
20 to 350 ml
Mnute Volume 2 to 50 L
Breathng rcut Pressure Range -10 to 100 cmHO
Rate 4 to 100 bpm
IE Rato 1  02 to 1 80 (normal operaton)
1  20 to 1  80 (effectve n support modes)
