3.3.6 Flow Tube - Total Combined Fresh Gas Flow
The flow tube (1) shows the combned flow of all gases
through the machne
3.3.7 Auxiliary Oxygen Flowmeter
The auxlary oxygen flowmeter (1) s suppled drectly from the
O supply, and wll contnue to delver oxygen f there s a total
power falure
Output s set by the control knob (2) and delvered through the
outlet (3)
3.3.8 Monitoring
• Arway pressure, measured from the expratory lmb of the
breathng crcut
• Tdal Volume and Mnute Volume dsplay s provded by a
dual sprometry system
• An ntegral oxygen montor system (fuel cell sensor type)
measures oxygen concentraton n the breathng crcut
nspratory lmb See secton 314
• Masmo Nomolne ISA Sdestream AX+ and OR+ modules
(optonal - see Appendx 7)
NOTE
If a Masmo Nomolne OR+ gas module wth
paramagnetc O montorng s ftted, the ntegral oxygen
montor system (fuel cell sensor type) s dsabled
Refer to Appendx 7
