3.1 General Construction
Frame
The machne has a cast alumnum base, extruded
alumnum uprghts, and plastc mouldngs
Moblty
astors (125 mm dameter), wth a brake (1) on each
A footrest s bult nto the front of the machne
A handle s provded at the front of the machne to ad
manoeuvrablty
Work surface and lghtng
The work surface has rased edges to retan
nstruments, vals etc
Loadng 30 kg, evenly dstrbuted
An LED lghtng unt, mounted under the top shelf (2),
provdes work-area lghtng
A three-poston swtch (3) allows selecton of
On dm lght
On brght lght
Off
Extractor Fan Outlet
AUTION
Do not obstruct the extractor fan outlet (4)
Mountng Systems
a) Top shelf ftted wth a secure X™ mountng
system (5) for patent montors
b) Upper and lower X™ compatble alumnum
uprghts (6), and medcal ral (7) for addtonal
accessory mountng
3. Description
3
4
5
6
7
6
1
2
