Penlon Prima 460 - Pressure Monitor Connections

Prma 460 76 User Manual
6 Press the menu swtch (9) on the front panel
7 Scroll down the man menu and select O Montor And
Sprometry (10)
8 Select SPIRO ALIBRATION
9 Press the wheel (11) to ntate calbraton
10 albraton s completed
11 Scroll to ESAPE FROM MENU
12 Press the wheel to confrm
6.5.2 Pressure Monitor Connections
WARNIN
The Hgh and Low Arway Pressure Alarms are mportant for
patent care
1 heck the tubng connectons at the Patent pressure port
(1) and the connector (2) adacent to the patent block at
the sde of the anaesthetc machne
Dsconnecton of arway pressure tubng, or pressure sensor
malfuncton
Message dsplayed ‘heck pressure sensng’
Acton by user
1 heck the condton of the tubng, and the connectons (1)
and (2)
2 If the tubng s undamaged and the connectons are
secure, the operaton of the sensors must be checked by a
servce engneer
AUTION
The ventlator wll contnue to functon, although the target
pressure may be exceeded by up to 10 cmHO
Pre-use Checks
11
9
10
2
1
