Penlon Prima 460 - Touchscreen; Touchscreen Functions

Prma 460 22 User Manual
Description
3.11 Touchscreen
3.11.1 Touchscreen functions - models with optional
Masmo ISA AX+ or ISA OR+ module
1 Fresh as dsplay - see also 3112
2 System menu and Ventlator waveform area
3 as mxture selecton wndow
4 Stopwatch
5 Mode selectors
6 Parameter area
7 Alert area
8 Symbol area (see also secton 3124)
9 Electrcal power status area
10 Message area
11 Masmo ISA AX+ and ISA OR+ module dsplay (f nstalled)
NOTE
Addtonal screen dsplays for optonal Masmo ISA AX+ and
ISA OR+ modules are shown n Appendx 7
Resettng varable parameter values
See secton 31274 (Selectng Functons and Parameters)
6
7
1
1
3
4
5
8
9
2 10
11
