Prma 460 30 User Manual
Description
VT MEAS/Vm MEAS
The parameter s shown as ether Tdal Volume or Mnute Volume
dependent on user set menu optons In standby mode ths
parameter s used to set ntal support pressure
The parameter dsplay component contans ether the ntal Target
Pressure / Support Pressure settngs, or a real-tme output of ether
measured tdal or mnute volume
The volume default dsplay type on reset s measured tdal volume
The volume dsplay type can be toggled between “tdal” and
“mnute” by the user usng the “Modes Menu”
The user can change VOLUME TYPE by touchng the screen on the
Adult / Paedatrc Icon, or Absorber Mode Icon, or Sgh Symbol Icon,
or Insp Pause Symbol Icon
The total range for the measured tdal volume dsplay s 0 to 2 L
The unts and resoluton used wll swtch accordng to the volume
sze
Below 1 ltre The dsplay wll show 0 to 990 mllltres wth a
resoluton of 10 ml
reater or equal to 1 ltre The dsplay wll show 100 to 200 ltres
wth a resoluton of 10 ml
The total range for the measured mnute volume dsplay s 00 to
500 ltres wth a resoluton of 100 ml
SET parameter dsplay
The set parameter dsplay shows three dfferent parameters,
dependent on the ventlaton mode selected
Ventlator mode Parameter Range Resoluton Reset Default
STANDBY / VV / PV Set IE rato 103 to 180 01 120
SPONT Measured IE rato 100 to 199 01 100
SIMV / SMMV / PSV Set nspre tme 10 to 50 seconds 01 seconds 20 seconds
BPM
The Set parameter dsplay shows, n all ventlator modes, the set
breathng rate
It s not possble to set a BPM value that wll result n the nspraton
tme beng less than 200 ms, or the requred drve flow fallng
outsde the range 2 to 75 L/mn Attempts to do ths may result n an
“INORRET RATE OR RATIO” alarm beng dsplayed
PEEP
The PEEP parameter shows set PEEP, set pressure parameter or
OFF The set PEEP parameter must be lmted to a maxmum of 10
cmHO below the set pressure target / lmt, f ths s not possble
then t should be set to “OFF”
LIMIT
Parameter lmts are shown below
Ventlator mode Parameter Range Resoluton Reset Default
STANDBY / VV / SIMV /
SMMV / SPONT
Set Pressure Lmt 10 to 80 cmHO 1 38
PV Set Target Pressure 5 to 70 cmHO 1 10
PSV Set Support Pressure 4 to 70 cmHO 1 4
To select the range 41 to 80 cmHO an addtonal confrmaton “RE-
ONFIRM HIH SETTIN” s requred
On entry to the pressure-controlled ventlator mode, the pressure
target parameter defaults to 10 cmHO
