5.3.2.3 Spirometry Interface
onnect the sprometry nterface cable (7) to the socket (8) at
the rear of the absorber
5.3.2.4 Spirometer Heater Cable
onnect the sprometer heater cable (9) to the socket at the
rear of the machne
5.3.2.5 Absorber Gas Path Heater Cable
onnect the absorber gas path heater cable (10) to the socket
(11) adacent to the patent block on the sde of the machne
5.3.2.6 Oxygen monitor sensor cable (fuel cell sensor)
onnect the oxygen montor cable to the oxygen sensor (12)
and the socket (13) adacent to the patent block on the sde of
the machne
NOTE
If a Masmo Nomolne ISA AX+ or OR+ Module s ftted, the
ntegral oxygen montor system (fuel cell sensor type) s
dsabled
5.3.2.7 Exhaust port
onnect the Exhaust gas outlet (14) to the anaesthetc gas
scavenge system Y-pece Refer to secton 57
