3.86
9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
12.Use new camshaft sprocket retaining bolts
t
upon
assembly. Install the top bolt in each camshaft
sprocket. Do not torque the bolts at this time.
IMPORTANT
Use NEW sprocket retaining bolts upon assembly.
13.Verify cam timing is correct. Flywheel TDC mark
should still be aligned (see Step 1) and cam sprocket
markings should line up as shown.
ENGINE / COOLING / HVAC SYSTEM
