Polaris RANGER XP 1000 2018-2019

7
9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
7.27
14.Inspect roll cage sliding surface. This surface must be
clean and free of nicks, burrs or scratches. Inspect
the H-springs, but do not remove them from the
roll cage.
15.Inspect the armature plate for a consistent wear
pattern. Uneven wear of the armature plate indicates
a warped plate, which may cause intermittent
operation.
NOTICE
See Troubleshooting, Front Gearcase (ADC)page 7.31
for more details.
16.Drill a hole in the input shaft seal
d
and remove the
seal using a pry bar or seal puller.
17.Remove the snap ring
f
retaining the input shaft
assembly.
18.Remove the input shaft assembly. Inspect the pinion
gear
g
for chipped, broken, or missing teeth. Inspect
the input shaft bearing
h
for signs of wear. Replace
the input shaft cover O-ring prior to reassembly.
19.Inspect the input shaft bushing
j
for wear.
FINAL DRIVE
