PoolCop Evolution - Figure 18 - Speck Badu Eco-Touch; Figure 19 - Speck Badu Eco Motion

P o o l C o p M a n u a l : V 4 2 EN P a g e | 27
www.poolcop.com PCFR
Speck BADU Eco Touch, ACIS VIPool MKB VS
Figure 18 - Speck Badu Eco-Touch
Speck BADU 90 Eco Motion
Figure 19 - Speck Badu Eco Motion
Speed Pump Aux1 Aux2 Aux3
STOP Pulse ON OFF OFF OFF
1 OFF ON OFF OFF
2 OFF OFF ON OFF
3 OFF OFF OFF ON
BADU Eco Touch-Pro
Speed Pump Aux1 Aux2 Aux3
STOP OFF OFF OFF OFF
1 ON OFF OFF OFF
2 ON ON OFF OFF
3 ON OFF ON OFF
4 ON OFF OFF ON
BADU 90 Eco Motion
