PoolCop Evolution - Figure 20 - Zodiac Flopro VS; Figure 21 - Invertek Optidrive E2 Inverter

P a g e | 28 P o o l C o p M a n u a l : V 4 2 EN
www.poolcop.com PCFR
Zodiac FloPro VS
Figure 20 - Zodiac FloPro VS
Invertek Optidrive inverter e
2
Figure 21 - Invertek Optidrive e2 inverter
Speed Pump Aux1 Aux2 Aux3
STOP OFF OFF OFF OFF
1 ON ON OFF OFF
2 ON OFF ON OFF
3 ON OFF OFF ON
ZODIAC FloPro VS
Speed Pump Aux1 Aux2 Aux3
STOP OFF OFF OFF OFF
1 ON OFF OFF OFF
2 ON ON OFF OFF
3 ON OFF ON OFF
4 ON ON ON OFF
5 ON OFF OFF ON
INVERTEK OPTIDRIVE
