ORP Control
Set disinfectant parameters
based on ORP control
ORP C O N T R OL
Installed
: YES
Disinfectant
: Chlor
SetPoint
: 680 mV
Boost on
: Mon
Boost to
: 720 mV
Priming
: OFF
S E L E C T
QUIT
5.4.3.1.1 Installed
If INSTALLED: YES, PoolCop will control the ORP according to set point value.
ORP Control display will be activated; ORP Control Alerts will be activated.
If set to NO, these functions are deactivated.
Text: Installed
Default: NO
Entries: YES;
NO
5.4.3.1.2 Disinfectant
Set the disinfection option and algorithms used.
READ: Read and display only; no control
CHLOR: Chlorine dosing
SALT: External Salt System control
BROMI: Bromine dosing
OTHERS: for other situations, algorithm not optimized.
Text: Disinfectant
Default: Read
Entries: Read;
Chlor;
Salt;
Bromi;
Other
5.4.3.1.3 Setpoint
Set the desired ORP value; a typical Setpoint is 650 – 720.
The ideal Setpoint varies with water treatment options, and according to refill water
types.
Text: Setpoint
Default: 680
Entries: 300… 990mV
5.4.3.1.4 Boost on
If hyper-chlorination is desired, set a day of the week.
Text: Boost on
Default: None
Entries: None;
Mon;
Tue;
Wed;
Thu;
Fri;
Sat;
Sun
5.4.3.1.5 Boost to
If a day of the week is set for hyper-chlorination, set the desired the ORP value. Can’t
be lower than Setpoint
Text: Boost to
Default: 680
Entries: Setpoint… 990mV
5.4.3.1.6 Priming
Ensure dosing pump is connected to Aux6 and correctly powered.
Commanding priming ON will activate Aux6 for 60 seconds allowing the dosing pump
to prime. Priming is stopped when quitting the menu or after 60 seconds.
Text: Priming
Default: OFF
Entries: ON;
OFF
