3.6 INSTALLING OPTIONS
Various PoolCop options are available. These serve to increase autonomy and enhance functionality.
Air Temperature Sensor
The optional Air Temperature sensor measures outside air temperature, displays this on the screen, and the temperature is used for
antifreeze protection if this protection is configured in the Pool Data menu.
Disconnect all electrical power to the pool and systems.
Switch the PoolCop OFF and open the CCU.
Fit the Air Temperature Sensor to J27
Figure 32 - Air temperature sensor J27
Route the sensor and cable via a compression gland to a location where external air temperature is representative of actual
temperature to which the pool surface is exposed. Secure the sensor cable in an appropriate manner.
CAUTION:
Keep a minimum distance of 10cm between the air temperature sensor cable and any 220V/380V power
cable to avoid disturbance due to capacitive coupling.
