3.7 COMPLETING THE INSTALLATION
Verify that all wiring has been done according to applicable electrical norms.
Replace the Power Supply Card PCB in J22.
Replace the battery and connect the terminal cables. Verify polarity.
Verify that the pH or pH+ORP electrode or blanking plug is secure, with O-ring in place.
Verify that the pressure tube is pushed over the nipple on the main base and over the nipple on the pressure transducer
on the centre Analogue PCB of the Valve Data Unit.
Verify that the power switch on the CCU is in the OFF position (switch to UP).
Connect the circuit breakers to the PoolCop and associated equipment.
3.8 COMMISSIONING POOLCOP
Switch the Control Connection Unit ON.
o The Power ON and Battery ON LED’s must illuminate.
CAUTION:
If this equipment stays on for longer than 2 seconds, IMMEDIATELY switch OFF the CCU.
Recheck all connections.
If only the pump runs, disconnect the circuit breaker, switch ON the PoolCop and reset factory default
settings. Now reconnect the pump circuit breaker and continue with commissioning.
The PoolCop will display the following sequence:
o Welcome note with firmware version (5 seconds).
o Pump OFF.
o FILTER position selected and valve might rotate to filter position.
o Once filter position is confirmed, the main screen will be displayed.
Open all appropriate valves and remove any stoppers or plugs in the filtration system.
CAUTION:
If leaks are found, switch OFF the CCU.
Repair all leaks and repeat the procedure, if required.
Switch the pump ON from the MANUAL CONTROL menu.
With the pump and filtration running, carefully check for leaks, especially in the following places:
o pH sensor or blanking plug.
o Ionizer electrodes or blanking plugs (4).
o Pressure tube and sensor.
o Seal between Valve Data Unit base and/or 2” Adapter and the multiport valve housing.
o Filter connectors.
o All valves and pipe connectors.
Verify correct functioning of auxiliaries by switching them ON/OFF in the MANUAL CONTROL menu.
Close the CCU cover.
