Outputs (relays) table:
Function
Relay
Label
Relay
ID
Connector
Rating
Examples of possible use
AUX
AUX8
K1
J2
6A/230V
Pool heating, booster pump, Garden lighting, irrigation, etc.
AUX
AUX9
K2
J2
6A/230V
Pool heating, booster pump, Garden lighting, irrigation, etc.
AUX
AUX10
K3
J2
6A/230V
Pool heating, booster pump, Garden lighting, irrigation, etc.
AUX
AUX11
K4
J2
6A/230V
Pool heating, booster pump, Garden lighting, irrigation, etc.
AUX
AUX12
K5
J1
6A/230V
Pool heating, booster pump, Garden lighting, irrigation, etc.
AUX
AUX13
K6
J1
6A/230V
Jetstream (*),
Pool heating, booster pump, Garden lighting, irrigation, etc.
AUX
AUX14
K7
J1
6A/230V
Pool Cover open command(*),
Pool heating, booster pump, Garden lighting, irrigation, etc.
AUX
AUX15
K8
J1
6A/230V
Pool Cover close command (*),
Pool heating, booster pump, Garden lighting, irrigation, etc.
Table 4 Relays and Power Ratings
(*) see extras functionalities in 5.6.6 Equipment
WARNING:
Never exceed the power ratings.
Always conform to local installation norms and requirements.
CAUTION:
If you are unsure of the applicable wattage rating, contact the distributor of the auxiliary apparatus to
confirm prior to connection.
Inputs table:
Function
Input
Label
Connector
Examples of possible use
INPUT
IN3-GND
J11
Consumables low, pump start, pump stop, pool cover, etc.
INPUT
IN4-GND
J11
Consumables low, pump start, pump stop, pool cover, etc.
INPUT
IN5-GND
J11
Consumables low, pump start, pump stop, pool cover, etc.
INPUT
IN6-GND
J11
Consumables low, pump start, pump stop, pool cover, etc.
INPUT
IN7-GND
J12
Consumables low, pump start, pump stop, pool cover, etc.
INPUT
IN8-GND
J12
Consumables low, pump start, pump stop, pool cover, etc.
INPUT
IN9-GND
J12
Jetstream control (*),
Consumables low, pump start, pump stop, pool cover, etc.
INPUT
IN10-GND
J12
Consumables low, pump start, pump stop, pool cover(*), etc.
Table 5 Inputs Table
CAUTION:
Inputs are self-powered with low voltage
Only use potential free signal without any external power supply.
(*) see extras functionalities in 5.6.6 Equipment
