Inputs role
The inputs can be assigned to various functions, and the setting is used to inform the software functions assigned to each entry.
The following predefined functions are available:
Default, the input is not active.
The connection of an external antifreeze thermostat assists in protection against damage
due to freezing. When detected and if the mode is activated in POOL DATA menu, anti-
freeze protection is activated, and filtration is started, and is accompanied by an alert.
The connection of a consumables low level detector (typically a float switch on a suction
wand) triggers an alert when low level is detected. This alert is dedicated to disinfection
consumables.
The connection of a consumables low level detector (typically a float switch on a suction
wand) triggers an alert when low level is detected. This alert is dedicated to pH control
consumables.
If two chemical level sensors are combined, (for example one for disinfection and one for
pH control) these two signals can be wired in parallel, so that a single signal can trigger
the “Consumable” alert. This is useful when the second input is required for another
action, such as pool cover position for example.
To reduce the duration of filtration (if in ECO+ mode) and ionization when the cover is
closed. Generates an alarm in the non-closed position. If the pool is equipped with a
variable speed pump, PoolCop switches on the speed n ° 1. When the cover is re-opened
during a cycle of operation of the pump, the speed associated with this cycle is restored.
If a filtration cycle is running when the cover is closed, this cycle will not be affected by
reduction. Only the following cycles will be affected.
With a compatible salt water chlorination system installed and connected, the LOW SALT
and/or SHUTDOWN feature will trigger an alert message “Salt System: Intervention
Required”
The input can be used to command the filtration to run by means of an external run
command, from a switch, button or an external automation. Removing this input
command will stop the filtration unless ON in another mode.
The input can be used to stop the filtration using an external control. Warning: This
decision overrides any other orders including antifreeze protection. If a filter cleaning is
in progress when the request occurs, it will be stopped, but the filter will be rinsed.
The input can be used to toggle a Jetstream pump. The action will be taken when a
Jetstream Equipment is declared (see 5.6.6 Equipment for further details).
Note: the delay is used to filter too rapid and therefore irrelevant events.
