MULTI GAUGE CONTROLLER COMMUNICATION
continued from previous page
NAME OF VARIABLE ADDRESS TYPE KIND RANGE [UNIT]
Setpoint 6 source 67 R/W UINT8 see tab. 6.21
Setpoint 7 source 68 R/W UINT8 see tab. 6.21
Setpoint 8 source 69 R/W UINT8 see tab. 6.21
Setpoint 9 source 70 R/W UINT8 see tab. 6.21
Setpoint 10 source 71 R/W UINT8 see tab. 6.21
VACUUM CHANNEL 1 - PASSIVE GAUGE 1
Channel 1 - Emission ON/OFF 72 R/W UINT8 0 .. 1
Channel 1 - Degassing ON/OFF 73 R/W UINT8 0 .. 1
Channel 1 - Gauge type 74 R/W UINT8 see tab. 6.17
Channel 1 - Emission control 75 R/W UINT8 see tab. 6.19
Channel 1 - ilter: 0 - Low
1 - Medium
2 - High
76 R/W UINT8 0 .. 2
Channel 1 - Gas type 77 R/W UINT8 see tab. 6.20
Channel 1 - def. correction factor 78 R/W UINT16 0 .. 999
Channel 1 - Degassing time 79 R/W UINT8 0 .. 20 [min]
Channel 1 - current time to complete degassing (min) 80 R UINT8 0 .. 20 [min]
Channel 1 - current time to complete degassing (sec) 81 R UINT8 0 .. 59 [sek]
Channel 1 - Degassing power 82 R/W UINT8 1 .. 40 [W]
Channel 1 - Filament selection 83 R/W UINT8 1 .. 2
Channel 1 - Sensitivity 84 R/W UINT8 1 .. 100
Channel 1 - Emission current 85 R/W UINT16 10 .. 1000 [10uA]
Channel 1 - Calibration factor 86 R/W UINT16 1 .. 2000
Channel 1 - Grid voltage of def. gauge 87 R/W UINT8 20 .. 250 [V]
Channel 1 - Filament voltage of def. gauge 88 R/W UINT8 0 .. 120 [V]
Channel 1 - Relector voltage of def. gauge 89 R/W UINT8 0 .. 120 [V]
Channel 1 - Degas voltage of def. gauge 90 R/W UINT16 400 .. 600 [V]
Channel 1 - Max. ilament current of def. gauge 91 R/W UINT8 10 .. 60 [100mA]
VACUUM CHANNEL 2 - PASSIVE GAUGE 2
Channel 2 - Emission ON/OFF 92 R/W UINT8 0 .. 1
Channel 2 - Degassing ON/OFF 93 R/W UINT8 0 .. 1
Channel 2 - Gauge type 94 R/W UINT8 see tab. 6.17
Channel 2 - Emission control 95 R/W UINT8 see tab. 6.19
Channel 2 - ilter: 0 - Low
1 - Medium
2 - High
96 R/W UINT8 0 .. 2
Channel 2 - Gas type 97 R/W UINT8 see tab. 6.20
Channel 2 - def. correction factor 98 R/W UINT16 0 .. 999
Channel 2 - Degassing time 99 R/W UINT8 0 .. 20 [min]
Channel 2 - current time to complete degassing (min) 100 R UINT8 0 .. 20 [min]
Channel 2 - current time to complete degassing (sec) 101 R UINT8 0 .. 59[sec]
Channel 2 - Degassing power 102 R/W UINT8 1 .. 40 [W]
Channel 2 - Filament selection 103 R/W UINT8 1 .. 2
Channel 2 - Sensitivity 104 R/W UINT8 1 .. 100
Channel 2 - Emission current 105 R/W UINT16 10 .. 1000 [10uA]
Channel 2 - Calibration factor 106 R/W UINT16 1 .. 2000
(*) - the unit depends on the Flux Monitor ON/OFF option
continued on next page
User manual rev. 03 Page 101
