COMMUNICATION MULTI GAUGE CONTROLLER
continued from previous page
NAME OF VARIABLE ADDRESS TYPE KIND RANGE [UNIT]
Channel 2 - Grid voltage of def. gauge 107 R/W UINT8 20 .. 250 [V]
Channel 2 - Filament voltage of def. gauge 108 R/W UINT8 0 .. 120 [V]
Channel 2 - Relector voltage of def. gauge 109 R/W UINT8 0 .. 120 [V]
Channel 2 - Degas voltage of def. gauge 110 R/W UINT16 400 .. 600 [V]
Channel 2 - Max. ilament current of def. gauge 111 R/W UINT8 10 .. 60 [100mA]
VACUUM CHANNEL 3 - PASSIVE GAUGE 3
Channel 3 - Emission ON/OFF 112 R/W UINT8 0 .. 1
Channel 3 - Degassing ON/OFF 113 R/W UINT8 0 .. 1
Channel 3 - Gauge type 114 R/W UINT8 see tab. 6.17
Channel 3 - Emission control 115 R/W UINT8 see tab. 6.19
Channel 3 - ilter: 0 - Low
1 - Medium
2 - High
116 R/W UINT8 0 .. 2
Channel 3 - Gas type 117 R/W UINT8 see tab. 6.20
Channel 3 - def. correction factor 118 R/W UINT16 0 .. 999
Channel 3 - Degassing time 119 R/W UINT8 0 .. 20 [min]
Channel 3 - current time to complete degassing (min) 120 R UINT8 0 .. 20 [min]
Channel 3 - current time to complete degassing (sec) 121 R UINT8 0 .. 59[sec]
Channel 3 - Degassing power 122 R/W UINT8 1 .. 40 [W]
Channel 3 - Filament selection 123 R/W UINT8 1 .. 2
Channel 3 - Sensitivity 124 R/W UINT8 1 .. 100
Channel 3 - Emission current 125 R/W UINT16 10 .. 1000 [10uA]
Channel 3 - Calibration factor 126 R/W UINT16 1 .. 2000
Channel 3 - Grid voltage of def. gauge 127 R/W UINT8 20 .. 250 [V]
Channel 3 - Filament voltage of def. gauge 128 R/W UINT8 0 .. 120 [V]
Channel 3 - Relector voltage of def. gauge 129 R/W UINT8 0 .. 120 [V]
Channel 3 - Degas voltage of def. gauge 130 R/W UINT16 400 .. 600 [V]
Channel 3 - Max. ilament current of def. gauge 131 R/W UINT8 10 .. 60 [100mA]
VACUUM CHANNEL 4 - ACTIVE GAUGE 1
Channel 4 - Emission ON/OFF 132 R/W UINT8 0 .. 1
Channel 4 - Degassing ON/OFF 133 R/W UINT8 0 .. 1
Channel 4 - Auto identiication 134 R/W UINT8 0 .. 1
Channel 4 - Gauge type 135 R/W UINT8 see tab. 6.17
Channel 4 - Emission control 136 R/W UINT8 see tab. 6.19
Channel 4 - ilter: 0 - Low
1 - Medium
2 - High
137 R/W UINT8 0 .. 2
Channel 4 - Gas type 138 R/W UINT8 see tab. 6.20
Channel 4 - def. correction factor 139 R/W UINT16 0 .. 999
Channel 4 - Degassing time 140 R/W UINT8 0 .. 20 [min]
Channel 4 - current time to complete degassing (min) 141 R UINT8 0 .. 20 [min]
Channel 4 - current time to complete degassing (sec) 142 R UINT8 0 .. 59[sec]
Channel 4 - Factor A of def. gauge 143 R/W INT16 -30000 .. 30000
Channel 4 - Factor B of def. gauge 144 R/W INT16 -30000 .. 30000
Channel 4 - Min. voltage of def. gauge 145 R/W UINT16 0 .. 10000
Channel 4 - Max. voltage of def. gauge 146 R/W UINT16 0 .. 10000
(*) - the unit depends on the Flux Monitor ON/OFF option
continued on next page
Page 102 User manual rev. 03
