MULTI GAUGE CONTROLLER COMMUNICATION
continued from previous page
NAME OF VARIABLE ADDRESS TYPE KIND RANGE [UNIT]
Channel 4 - Full scale parameter of def. gauge 147 R/W FLOAT 0.00001 .. 40000.00000
[Torr]
VACUUM CHANNEL 5 - ACTIVE GAUGE 2
Channel 5 - Emission ON/OFF 149 R/W UINT8 0 .. 1
Channel 5 - Degassing ON/OFF 150 R/W UINT8 0 .. 1
Channel 5 - Auto identiication 151 R/W UINT8 0 .. 1
Channel 5 - Gauge type 152 R/W UINT8 see tab. 6.17
Channel 5 - Emission control 153 R/W UINT8 see tab. 6.19
Channel 5 - ilter: 0 - Low
1 - Medium
2 - High
154 R/W UINT8 0 .. 2
Channel 5 - Gas type 155 R/W UINT8 see tab. 6.20
Channel 5 - def. correction factor 156 R/W UINT16 0 .. 999
Channel 5 - Degassing time 157 R/W UINT8 0 .. 20 [min]
Channel 5 - current time to complete degassing (min) 158 R UINT8 0 .. 20 [min]
Channel 5 - current time to complete degassing (sec) 159 R UINT8 0 .. 59[sec]
Channel 5 - Factor A of def. gauge 160 R/W INT16 -30000 .. 30000
Channel 5 - Factor B of def. gauge 161 R/W INT16 -30000 .. 30000
Channel 5 - Min. voltage of def. gauge 162 R/W UINT16 0 .. 10000
Channel 5 - Max. voltage of def. gauge 163 R/W UINT16 0 .. 10000
Channel 5 - Full scale parameter of def. gauge 164 R/W FLOAT 0.00001 .. 40000.00000
[Torr]
VACUUM CHANNEL 6 - ACTIVE GAUGE 3
Channel 6 - Emission ON/OFF 166 R/W UINT8 0 .. 1
Channel 6 - Degassing ON/OFF 167 R/W UINT8 0 .. 1
Channel 6 - Auto identiication 168 R/W UINT8 0 .. 1
Channel 6 - Gauge type 169 R/W UINT8 see tab. 6.17
Channel 6 - Emission control 170 R/W UINT8 see tab. 6.19
Channel 6 - ilter: 0 - Low
1 - Medium
2 - High
171 R/W UINT8 0 .. 2
Channel 6 - Gas type 172 R/W UINT8 see tab. 6.20
Channel 6 - def. correction factor 173 R/W UINT16 0 .. 999
Channel 6 - Degassing time 174 R/W UINT8 0 .. 20 [min]
Channel 6 - current time to complete degassing (min) 175 R UINT8 0 .. 20 [min]
Channel 6 - current time to complete degassing (sec) 176 R UINT8 0 .. 59[sec]
Channel 6 - Factor A of def. gauge 177 R/W INT16 -30000 .. 30000
Channel 6 - Factor B of def. gauge 178 R/W INT16 -30000 .. 30000
Channel 6 - Min. voltage of def. gauge 179 R/W UINT16 0 .. 10000
Channel 6 - Max. voltage of def. gauge 180 R/W UINT16 0 .. 10000
Channel 6 - Full scale parameter of def. gauge 181 FLOAT 0.00001
..
40000.00000
[Torr]
VACUUM CHANNEL 7 - ACTIVE GAUGE 4
Channel 7 - Emission ON/OFF 183 R/W UINT8 0 .. 1
Channel 7 - Degassing ON/OFF 184 R/W UINT8 0 .. 1
(*) - the unit depends on the Flux Monitor ON/OFF option
continued on next page
