ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 123/219
12.1 Quick Start checklist
This checklist lists all the steps to a quick usage of the PA module in Link or Coupler mode. It is assumed that a
running ComBricks set with at least one DP repeater module or fiber optic coupler module is already active.
STEP 1: Provide the Head Station 1B or 1C with the latest firmware, at least v1.279. (7)
STEP 2: Add an empty backplane slot to the ComBricks set. (2.2)
STEP 3: Configure the PA module to the same network as a DP repeater module.
NOTE: for monitoring mode, use a different and unused network! (2.4)
STEP 4: Insert the PA module in the empty slot. (2.3)
STEP 5: Check the Channel List (in web browser) to see if the PA module appears. (4.2)
For Monitoring Mode: skip to STEP 8.
STEP 6: Power the top of PA coupler module. (2.6)
STEP 7: Check the status page of the PA module: is DC voltage OK?
Not too much noise on DC? Current consumption ± 10mA? (12.2.1)
STEP 8: Connect the PA trunk cable with PA station(s). (12.5.1)
STEP 9: Check the status page of the PA module:
Current consumption increased? (12.2.1)
For Monitoring mode: Skip to STEP 11.
STEP 10: Use the GSD Converter to change the PA GSD files. (12.3.1)
STEP 11: Setup a master on the DP side. (12.4.1)
STEP 12: Check the Scope Signals of the PA trunk. (12.2.2)
