ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 103/219
10.4 LEDs
The table below explains the function of all the LEDs on the front plate of the Fiber Optic module:
OFF
Blinking
ON
RDY
Module has NOT been
powered / initialized yet.
Head Station is
initializing or updating the
module.
Module has been
initialized and is
operational
RX1 / RX2
NO signal, or NO valid
telegrams detected on this
channel, or channel is off.
1 or more devices are
communicating on this
channel.
A fiber optic cable is
connected and link is
established correctly
LV1 / LV2
Signal quality is good,
or channel is off.
Not possible
Low signal, received
messages can still be
decoded
ER1 / ER2
No errors, or channel
is off.
Not possible
No baudrate detected
or no connection/signal
10.5 Setting up Fiber Optic alarms
The webserver and the FO Ring module are capable of sending alarms on critical events in the fiber connection.
The following events can be reported:
• Signal quality deterioration and quality improvement
• Ring failing and ring established
On the module status page all vital module information is displayed. You can see the detected baudrate, and
channel 1 and 2 signal status. Also the ring status is displayed.
