30 Technical Data - 4 CH Relay Module (101-210210)
Technical Data - 4 Channel Relay Module (101-210210)
Backplane
Controllers
Modules
Power supply
Current consumption
Compatible backplane units
Web server, PROFINET IO device, PROFIBUS DP slave
32 (all slots)
Provided through the backplane
± 225 mA (465 mA max)
101-200011, 101-200012, 101-200023, 101-200024,
101-200027
Relays
Relays
Current
Voltage
Resistance
Toggles
4 (2 on the front, and 2 on the bottom)
5 A per relay
230 VAC
300 mOhm (including connectors)
100000 (at 5A - 230 VAC)
Connectors
Pins
Wire diameter (for the screw terminals)
Wire type
1 = No (normally open)
2 = Common
3 = Nc (normally closed)
< 2.5 mm
2
Stranded or solid core
Others
Head Station firmware
Dimensions
Operating temperature
Weight
MTBF
V1.260 and later
140 x 110 x 25 mm
0 .. 60 °C
125 g
To be defined
