ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 184/219
33 Technical Data RS-485-IS Barrier (101-201410)
Technical Data RS-485-IS Barrier (101-201410)
Backplane
PROFIBUS networks
Modules
Power supply
Current consumption
Compatible backplane units
4 (set by dipswitches or web server)
10 (positioned in the first 10 slots)
Provided through the backplane
± 450 mA (740 mA max)
101-200011, 101-200012, 101-200023, 101-200024,
101-200027
Protocol specifications
Supported Protocols
Address
Transmission speed
Transmission speed detection
Data delay time (normal mode)
Data delay time (redundant mode)
Delay time jitter
DP-V0, DP- V1, DP-V2, FDL, MPI, FMS, PROFIsafe, PROFIdrive
and any other FDL based protocol
No bus address required
9.6 kbps .. 1.5 Mbps (including 45.45 kbps)
Auto detect (< 10 s detection and 50 s lost time)
2.0 TBit
12.0 TBit
Max. ¼ TBit
Oscilloscope specifications
Frequency
Resolution
Differential range
192 MS/s
27 mV
-3.49 .. 3.49 V
PROFIBUS cable specifications
Cable lengths
Number of devices
Required termination
Redundancy
1200 m at 9.6 kbps .. 93.75 kbps
1000 m at 187.5 kbps
400 m at 500 kbps
200 m at 1.5 Mbps
Maximum 31 devices per channel (busloads)
DB9-IS connector with internal 200 only
Yes, maximum 10 cables activated by switch
Dipswitches
