Page #161 background image
ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 161/219
20 Technical Data - Head Station 1A/1B/1C
Technical Data - Head Station 1A/1B/1C
Type differences (Hardware is identical with all types)
Head Station 1A
Head Station 1B
Head Station 1C
For all Head Stations
No ProfiTrace OE
ProfiTrace OE for 1 PROFIBUS network +
ProfiTrace 2 live streaming + OPC (since June 2013)
ProfiTrace OE for 4 PROFIBUS networks +
ProfiTrace 2 live streaming + OPC
CommDTM
Backplane
Modules
Current available for the backplane
PROFIBUS networks
Compatible backplane units
32 (10 repeater modules positioned in the first 10 slots)
2.5 A
4
101-200012, 101-200023, 101-200024, 101-200027
Power supply specifications
Nominal supply voltage
Current consumption
Power
Reverse polarity protection
Redundant power supply
Wire diameter
10.8 .. 26.4 VDC
800 mA (fully loaded)
20 W
Yes
Yes
< 2.5 mm
2
Installation notes:
The device shall be supplied from an isolating transformer
having a secondary Listed fuse rated either:
Maximum 5 amps for voltages 12 .. 20 V, or
Maximum 4 amps for voltages 21 .. 24 V,
or is supplied by a Class 2 power supply, or equivalent.
Ethernet
Connector
Cable length
Link speed
MAC address
Supported protocols
Default IP address after reset/purchase
Connections
RJ-45
Max. 100 m
10 / 100 Mbps
9C.B2.06.xx.xx.xx (label on the side of the Head Station)
HTTP, FTP, SMTP, TELNET, DHCP, SNMP
192.168.1.254
20 simultaneous web server clients
Relay contact
