Page #77 background imageLoading...
Page #77 background image
ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 77/219
6.3.2 Life cycle of the SD card
The life of a SD card depends on the following factors:
Number of read and write operations
Ambient temperature
At an ambient temperature of up to 60 °C the SD card has a service life of 10-years at maximum 100000
write/delete sequences.
If the maximum number of read and write operations has exceeded the limits, data loss may be possible.
6.3.3 Directories and files
The following directories have been standardized for ComBricks and are in most cases located on the SD card;
Directories
Description
/Busmon
ProfiTrace message recording files
(Head Station type 1B and 1C only)
/Log
Log files
/Doc
Contains the web server download page
(See Paragraph 4.10 on how to set it up)
Files and extensions
Description
Journal.DAT
System file
(Do not delete or remove it)
GSD.BIN
File with GSD information for the Live List.
(Generated with the ProfiTrace 2 software).
See Paragraph 5.1.1 how to generate this file.
SETTINGS.INI
Head Station settings
(IP address, name, location, etc.)
LICxxxxxxx.TXT
License files
.PTC
ProfiTrace OE message recoding files. (located in the "Busmon" directory).
The files can be opened with ProfiTrace V2.5.3 and higher (See Paragraph
5.3 on how to generate PTC files).
.PKG
Firmware files
.CSV
Log files
(located in the "Log" directory)
