ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 149/219
15.2 Setting up a stream
To connect the ComBricks to ProfiTrace, see paragraph 5.8.
15.3 Selecting OPC tags
The OPC tag settings can be found in the Settings menu (see Fig. 105).
In the next dialog you can add tags (see Fig. 106). All basic tags are already available (Live List, and Statistics).
When you do not require additional tags, you do not have to enter this dialog and can you directly proceed to
the server settings.
The OPC tags are locations in the I/O data of the devices (offset 0 is the first location).
Be careful with too many tags. The quantity of tags can slow down your system, especially when
you want to run multiple applications at the same time. To solve this you can filter tags in the client
you are using.
You can save your data in a .PTO file which is used later during the setup of the OPC server.
