ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 188/219
35 Technical Data - PROFINET Device PND001
Technical Data - PROFINET PND001 (101-220110)
Backplane
Modules
Power supply
Current consumption
Compatible backplane units
Compatible partner/gateway modules
10 (positioned in the first 10 slots)
Provided through the backplane
± 410 mA typical (625 mA max)
101-200011, 101-200012, 101-200023, 101-200024,
101-200027
101-220210, 101-220110, 101-210210, 101-210110, 101-210010
PROFINET specifications
PROFINET conformance class
Supported protocols
Switch propagation time
Cycle times
PROFINET IO cyclic process image
Transferrable bytes to proxies
(inputs and outputs)
B
RT_CLASS_1, RTA, UDP, DCP, ARP, LLDP, SNMP (MIB II)
To be defined
1 ms - 1..128 input or output bytes
2 ms - 129..256 input or output bytes
4 ms - 257..512 input or output bytes
8 ms - 513..1024 input or output bytes
1024 input bytes, provider (IOPS) and consumer (IOCS) data
qualifiers bytes included.
• PND-001 module 4 bytes IOPS
• Each input module 1 byte IOPS
• Each output module 1 byte IOCS
1024 output bytes, provider (IOPS) and consumer (IOCS) data
qualifiers bytes included.
• PND-001 module 4 bytes IOCS
• Each output module 1 byte IOPS
• Each input module 1 byte IOCS
1, 2, 3, 4, 8, 12, 16, 20, 24, 28, 32, 64, 96, 128, 160, 192, 204
PROFINET cable and connector specifications
Technology standards
Transmission speed detection
Cable length
Connectors
100BaseTX, 10BaseT
Auto detect, Auto cross-over, Auto polarity
Max. 100 m
RJ-45
• 90 Degree connector for port 1 is not recommended.
• Shielded connectors are recommended.
