ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 189/219
Technical Data - PROFINET PND001 (101-220110)
PROFINET Device Name
Rotary switch
(the use of setting position 1..9
overrides the stored device name).
Maximum device name length
0 = Stored device name (set by software - DCP protocol)
1 = "ComBricks-1" .... 9 = "ComBricks-9"
63 characters separated by (.) or (-) and a total length of max 240
characters
LEDs
RDY (OFF)
RDY (blinking at 0.3Hz)
RDY (blinking at 1Hz)
RDY (ON)
RUN (ON)
SF (ON)
BF (OFF)
BF (blinking at 0.5 Hz)
BF (ON)
Module is not powered or module is faulty.
Module is receiving new firmware from the Head Station. Do not
remove module or power down the Head Station.
Module is communicating with the Head Station.
The communication with the Head Station is established.
Application is running
PROFINET configuration mismatch or system error
Device is in PROFINET Data Exchange.
No Data Exchange, but physical link established.
No physical link.
Certification, Approvals and Identification
Approvals
PROFINET certification number
GSD filename
GSD bitmap filename
Manufacturer / Product Ident Number
PNO PROFINET certificate (GSDML 2.25)
CE Emission acc. to EN 55022 (2006) + A1 (2007) class A
CE Immunity acc. to EN 55024 (1998) + A1 (2001) + A2 (2003)
level 10V/m 10Vrms
FCC Emission 47 CFR 15 class A
ZZ10500
GSDML-V2.25-PROCENTEC-ComBricks PND_001-20120831.xml
0x4000 hex - 0x0001 hex
Others
Head Station firmware
Operating temperature
Weight
MTBF
Version 1.264 or higher
0 .. 60 °C
111 g
To be defined
