ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 173/219
26 Technical Data - Fiber Optic Ring SM1 (101-201531)
Technical Data - Fiber Optic Ring SM1 (101-201531)
Backplane
PROFIBUS networks
Modules
Power supply
Current consumption
Compatible backplane units
4 (set by dipswitches or web server)
10 (positioned in the first 10 slots)
Provided through the backplane
t.b.d.
101-200011, 101-200012, 101-200023, 101-200024,
101-200027
Protocol specifications
Supported Protocols
Address
Transmission speed
Transmission speed detection
Fiber optic cable delay
Delay time (per ring module)
Total delay between 2 modules
DP-V0, DP- V1, DP-V2, FDL, MPI, FMS, PROFIsafe,
PROFIdrive and any other FDL based protocol
NO bus address required
9.6 kbps .. 12 Mbps (including 45.45 kbps)
Auto detect (< 10 s detection and 50 s lost time)
See manual for calculation
T.b.d.
See manual for Slot time adjustment calculation
Fiber optic specifications
Fiber Optic wavelength
Cable type
Cable length
Optical budget
Optical loss
Connectors
Topologies
Cascading depth
Single mode 1310 nm
Fiber 9 / 125 µm (OS1)
Max. 30 km (baudrate independent)
17dB
0.4dB per km
4 x ST/BFOC (2 channels)
Ring, point-to-point (direct, hub, split, star)
No limit, only busparameter limitation of the master
