ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 182/219
31 Technical Data - 8 CH D-out Module (101-210110)
Technical Data - 8 Channel Digital Out Module (101-210110)
Backplane
Controllers
Modules
Power supply module electronics
Power supply digital outputs
Current consumption module electronics
Compatible backplane units
Web server, PROFINET IO device, PROFIBUS DP slave
32 (all slots)
Provided through the backplane
Provided through an additional 3-pin connector
± 290 mA (465 mA max)
101-200011, 101-200012, 101-200023, 101-200024,
101-200027
Digital Outputs
Outputs
Current
Voltage range
Losses
8 Digital Outs on 1 connector
0.5 A per Digital Out (direct current)
15..30 VDC (depends on provided voltage)
0.211 Ohm loss per Digital Out
Power Connector
Pins power connector
Wire diameter (for the screw terminals)
Wire type
1 = -, 2 = +, 3 = SH
< 2.5 mm
2
Stranded or solid core
Digital Output Connector
Pins DO connector
Wire diameter (for the screw terminals)
Wire type
1 = GND, 2..9 = DO0..DO7, 10 = GND
< 1.5 mm
2
Stranded or solid core
Others
Head Station firmware
Dimensions
Operating temperature
Weight
MTBF
V1.260 and later
140 x 110 x 25 mm
0 .. 60 °C
105 g
To be defined
