ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 80/219
6.6 LEDs on the Head Station
In the tables below the LEDs of the Head Stations during normal operation are described. The LED conditions in
firmware update and menu mode are not described here.
RDY - Ready
OFF
Blinking
ON
Starting up
X
Run
X
ETH - Ethernet
OFF
Blinking
ON
No Ethernet link established
X
DHCP configuration is pending
X
Ethernet link established
X
SF - System failure on the Head Station
OFF
Blinking
ON
OK
X
Backplane voltage too low (under 5,5 VDC) or current draw
to high (above 2,5 A)
Fast
Clock-chip error
(contact your local Distributor or PROCENTEC)
Slow
Internal component or firmware error
(contact your local Distributor or PROCENTEC)
X
