ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 138/219
13.3 Quick Start checklist
This checklist lists all the steps to a quick usage of the PROFINET Device module as a Remote I/O station.
STEP 1: Provide the Head Station 1B or 1C with the latest firmware, at least v1.272. (7)
STEP 2: Add at least two empty backplane slots to the ComBricks set. (2.2)
STEP 3: Use the rotary switch on the bottom to assign a custom or pre-defined
name to the PROFINET device. (13.4)
STEP 5: Insert the PROFINET Device module in one empty slot. Do not insert it in slot
number 11 or higher; this is not supported by the ComBricks. (2.3)
STEP 6: Insert a DI/DO/Relay card in the other empty slot. (2.3)
STEP 7: Provide power to the Head Station. (4.2)
STEP 8: Connect the Head Station to the Ethernet network with an Ethernet cable. (4.2)
STEP 9: Connect a PROFINET cable and connector to one of the RJ45 connectors.
STEP 10: Check the Channel List (in web browser) to see if the modules appear. (4.2)
