Procentec ComBricks User Manual

ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 190/219
36 Technical Data - 6A Power Module T1 (101-230010)
Technical Data - 6A Power Module Type 1 (101-230010)
Backplane
Modules
Current consumption from the backplane
Compatible backplane units
32 (all slots)
± 130 mA (465 mA max)
101-200011, 101-200012, 101-200023, 101-200024,
101-200027
Backplane power
Current
Maximum combined backplane current
6 A
12 A (provided by all inserted power modules)
Power supply
Nominal supply voltage
Current consumption
Power
Reverse polarity protection
Redundant power supply
12 .. 30 VDC
Max. 2 A @ 24 VDC
Max. 42 W
Yes
Yes
Installation notes:
The device shall be supplied from an isolating transformer having a secondary Listed fuse rated either:
• Maximum 5 amps for voltages 12 .. 20 V, or
• Maximum 4 amps for voltages 21 .. 24 V, or is supplied by a Class 2 power supply, or equivalent.
When using the Power Module, remove power from the Head Station. If power redundancy is required,
use two Power Modules. When moving the Power Module to a different slot: remove power before taking
out the module.
Power supply connectors
Pins
Wire diameter (for the screw terminals)
Wire type
1 = - (left)
2 = + (middle)
3 = Ground (right)
< 2.5 mm
2
Stranded or solid core
LEDs
ERR ON
ERR + RUN OFF
Input voltage too low, or maximum current
No power supply connected
Others
Head Station firmware
Dimensions (L x W x H)
Operating temperature
Weight
At least version 1.265
140 x 110 x 25 mm
0 .. 60 °C
125 g
