Page #36 background image
ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 36/219
3.10 Configuring repeater modules
The repeaters can be configured using the dipswitches located at the front of the module or the web server.
3.10.1 Customizing the PROFIBUS network (NW0/NW1)
Set these dipswitches to the following positions to customize a network number for a specific PROFIBUS
network.
NW0
NW1
Network
LEFT
LEFT
1
RIGHT
LEFT
2
LEFT
RIGHT
3
RIGHT
RIGHT
4
When software settings are preferred these dipswitches do not have to be set.
3.10.2 Redundancy (RED)
Set this dipswitch to enable the redundancy group for the channel.
RED
Redundancy
LEFT
OFF
RIGHT
ON
When software settings are preferred this dipswitch does not have to be set.
