ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 163/219
21 Technical Data - SCOPE Repeater (101-201210)
Technical Data - SCOPE Repeater (101-201210)
Backplane
PROFIBUS networks
Modules
Power supply
Current consumption
Compatible backplane units
4 (set by dipswitches or web server)
10 (positioned in the first 10 slots)
Provided through the backplane
± 400 mA (555 mA max)
101-200011, 101-200012, 101-200023, 101-200024,
101-200027
Protocol specifications
Supported Protocols
Address
Transmission speed
Transmission speed detection
Data delay time (normal mode)
Data delay time (redundant mode)
Delay time jitter
DP-V0, DP- V1, DP-V2, FDL, MPI, FMS, PROFIsafe, PROFIdrive
and any other FDL based protocol
NO bus address required
9.6 kbps .. 12 Mbps (including 45.45 kbps)
Auto detect (< 10 s detection and 50 s lost time)
2.0 TBit at 9.6 kbps .. 3 Mbps
2.75 TBit at 6 Mbps
3.75 TBit at 12 Mbps
12.0 TBit at 9.6 kbps .. 3 Mbps
12.75 TBit at 6 Mbps
13.75 TBit at 12 Mbps
Max. ¼ TBit
Oscilloscope specifications
Frequency
Resolution
Differential range
192 MS/s
50 mV
-6.436 .. 6.436 V
PROFIBUS cable specifications
Cable lengths
Wire diameter (for the screw terminals)
Wire type
Number of devices
Termination
Cascading depth
Redundancy
1200 m at 9.6 kbps .. 93.75 kbps
1000 m at 187.5 kbps
400 m at 500 kbps
200 m at 1.5 Mbps
100 m at 3 Mbps .. 12 Mbps
< 1.5 mm
2
Stranded or solid core
Maximum 31 devices per channel (busloads)
Integrated (switchable - PB RS-485 - 390/220/390 Ohms)
No limit, only busparameter limitation of the master
Yes, maximum 10 cables activated by switch
