32 Technical Data - 8 CH D-in Module (101-210010)
Technical Data - 8 Channel Digital In Module (101-210010)
Backplane
Controllers
Modules
Power supply
Current consumption
Compatible backplane units
PROFINET IO device, PROFIBUS DP slave
32 (all slots)
Provided through the backplane
Typ. ±169 mA (465 mA max)
101-200011, 101-200012, 101-200023, 101-200024,
101-200027
Digital Inputs
Inputs
Power per input
Signal Voltage for ‘1’
Input detection frequency
8 digital inputs on 1 connector
240 mW at 24 V
3 .. 32 VDC
Max. 3 ms
Digital Input Connector
Pins of Digital Inputs connector
Wire diameter (for the screw terminals)
Wire type
1 = GND, 2..9 = DI0..DI7, 10 = GND1
< 1.5 mm
2
Stranded or solid core
Others
Head Station firmware
Dimensions (L x W x H)
Operating temperature
Weight
MTBF
V1.271 and later
140 x 110 x 25 mm
0 .. 60 °C
100 g
To be defined
