ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 90/219
7.11 LEDs of the repeater module
The LEDs on the repeater modules are very useful for visual diagnostics.
Table 5 - LEDs on the standard repeater module
OFF
Blinking
ON
RDY
Repeater module has
NOT been configured yet.
Head Station is
configuring the repeater
module.
Repeater module has
been configured and is
operational
RX
NO valid telegrams
detected on this channel.
1 or more devices are
communicating on this
channel.
1 or more devices are
communicating on this
channel.
ER
The baudrate has
been detected.
Problem in the
cabling has been detected
on this channel.
This channel has not
detected the baudrate (yet)
or there is a problem with
the wiring of the cable.
SW
Internal termination for
this channel is OFF.
Internal termination for
this channel has been
activated.
Table 6 - Additional LEDs on the SCOPE repeater module
OFF
Blinking
ON
MIN
Valid telegram signal
amplitude (> 2.5 V)
Telegram signal
amplitude is too low
(< 2.5 V)
TERM
Valid idle voltage
(~ 1 V).
Idle voltage is too low
(< 1 V)
HWE
Repeater is
operational.
Internal repeater
error (contact PROCENTEC)
