ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 157/219

COMbricks is

connected to USB

and in the update

mode

Click here to browse

to the .pkg file

This window can be

closed directly, but wait

until COMbricks is ready

(check LEDs)

Fig. 111 - Firmware update cable

Fig. 112 - Firmware update tool
