ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 203/219

Termination

A (powered) resistor network at both ends of a segment to prevent reflections

(with PROFIBUS DP the termination has to be powered).

Topology

In a communications network, the pattern of interconnection between network

nodes; e.g. bus, ring, star configuration.
