ComBricks User Manual v6.4.0 | January 18| © PROCENTEC 74/219
Statistics
Description
Critical
External Diag
All responses from Get Diagnostics requests from all masters.
NO
Diag while in DX
Only responses to Get Diagnostics requests from the master that
controls this slave (primary class 1 master).
• When the first 2 bytes of the diagnostic content contains a 08
0C or 08 04, a red indicator blinks in the left corner of the
device in the Live List (critical content).
YES
(in most
cases)
Master lost
One of the masters is not active after getting the token; it is not
responding anymore. Note that this also happens when a Class 2
DP-V1 master is disabled.
YES
(in most
cases)
Baudrate change
The detected baudrate of the PROFIBUS network has been
changed.
YES (in most
cases)
Low/High signal
(Bargraph)
At least one station has a too low (in DP and PA networks) or too
high (in PA networks only) amplitude.
YES
Redundancy Failure
One of the redundant cables has failed.
NO
PA/FF signal and levels
PA or FF values such as jitter, DC voltage or DC noise out of
range.
YES
High/Low signal Fiber
Optic
Fiber Optic signal is out of range.
YES
Ring Failure (fiber
optic)
Fiber Optic ring is broken.
YES
