Q2 Q2A User Manual

Electrical Installation
3
3.15 Protect the Drive during Failures
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 113
Table 3.18 Factory-Recommended Branch Circuit Protection: 200 V Class (HD)
Drive Model
Maximum Applicable Motor Output
kW (HP)
Input Current Rating
A
Semiconductor Protection Fuse
Rated Current
Manufacturer: EATON/Bussmann
2004 0.55 (0.5) 3.6 FWH-45B
2006 0.75 (1) 4.8 FWH-45B
2010 1.5 (2) 8.9 FWH-45B
2012 2.2 (3) 12.7 FWH-50B
2018 3 (4) 17 FWH-80B
2021 3.7 (5) 20.7 FWH-80B
2030 5.5 (7.5) 30 FWH-125B
2042 7.5 (10) 40.3 FWH-150B
2056 11 (15) 58.2 FWH-200B
2070 15 (20) 78.4 FWH-225A
2082 18.5 (25) 96
FWH-225A
FWH-250A
*1
2110 22 (30) 82
FWH-225A
FWH-250A
*1
2138 30 (40) 111
FWH-275A
FWH-300A
*1
2169 37 (50) 136
FWH-275A
FWH-350A
*1
2211 45 (60) 164
FWH-325A
FWH-450A
*1
2257 55 (75) 200 FWH-600A
2313 75 (100) 271 FWH-800A
2360 90 (125) 324 FWH-1000A
2415 110 (150) 394 FWH-1000A
*1 A fuse with a large rated current for applications with repeated loads is recommended.
◆ Branch Circuit Protection for 400 V Class (ND)
Use the fuses specified in this document to prepare the drive for use on a circuit that supplies not more than
100,000 RMS symmetrical amperes and 480 Vac when there is a short circuit in the power supply.
The built-in short circuit protection of the drive does not provide branch circuit protection. The user must provide
branch circuit protection as specified by the National Electric Code (NEC), the Canadian Electric Code, Part I
(CEC), and local codes.
Table 3.19 Factory-Recommended Branch Circuit Protection: 400 V Class (ND)
Drive Model
Maximum Applicable Motor Output
kW (HP)
Input Current Rating
A
Semiconductor Protection
Fuse Rated Current
Manufacturer: EATON/
Bussmann
Input Voltage < 460 V Input Voltage ≥ 460 V
4002 0.75 (1) 0.75 (1) 2.5 FWH-50B
4004 1.5 (2) 1.5 (2) 4.7 FWH-50B
4005 2.2 (3) 2.2 (3) 6.7 FWH-50B
4007 3.0 (4) 3.0 (4) 8.9 FWH-60B
4009 4.0 (5) 3.7 (5) 11.7 FWH-60B
4012 5.5 (7.5) 5.5 (7.5) 15.8 FWH-60B
4018 7.5 (10) 7.5 (10) 21.2 FWH-80B
4023 11 (15) 11 (15) 30.6 FWH-90B
4031 15 (20) 15 (20) 41.3 FWH-150B
4038 18.5 (25) 18.5 (25) 50.5 FWH-200B
4044 22 (30) 22 (30) 59.7 FWH-200B
