Parameter List
11
11.6 E: MOTOR
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 435
No.
(Hex.)
Name Description
Default
(Range)
Ref.
E3-10
(0320)
M2 Min Out Voltage
Sets the minimum output voltage for the motor 2 V/f pattern.
Determined by E3-01
(400 V Class: 0.0 - 510.0
V)
640
E3-11
(0345)
Expert
M2 Mid B Frequency
Sets a middle output frequency for the motor 2 V/f pattern. Set this parameter to adjust
the V/f pattern for the constant output range. Usually it is not necessary to change this
setting.
0.0 Hz
(0.0 - E3-04)
640
E3-12
(0346)
Expert
M2 Min Out Voltage
Sets a middle output voltage for the motor 2 V/f pattern. Set this parameter to adjust the
V/f pattern for the constant output range. Usually it is not necessary to change this
setting.
0.0 V
(400 V Class: 0.0 - 510.0
V)
641
E3-13
(0347)
Expert
M2 Base Voltage
Sets the base voltage for the motor 2 V/f pattern. Set this parameter to adjust the V/f
pattern for the constant output range. Usually it is not necessary to change this setting.
0.0 V
(400 V Class: 0.0 - 510.0
V)
641
◆ E4: MOTOR 2 PARAMETERS
No.
(Hex.)
Name Description
Default
(Range)
Ref.
E4-01
(0321)
M2 Rated Current (FLA)
Sets the motor rated current for motor 2 in amps.
Determined by o2-04
and C6-01
(10% to 200% of the
drive rated current)
641
E4-02
(0322)
M2 Rated Slip
Sets the motor rated slip for motor 2.
Determined by o2-04
and C6-01
(0.000 - 20.000 Hz)
641
E4-03
(0323)
M2 No-Load Current
Sets the no-load current for motor 2 in amps when operating at the rated frequency and
the no-load voltage.
Determined by o2-04
and C6-01
(0 to E4-01)
642
E4-04
(0324)
M2 Pole Count
Sets the number of poles for motor 2.
4
(2 - 120)
642
E4-05
(0325)
M2 L-L Resistance
Sets the line-to-line resistance for the motor 2 stator windings.
Determined by o2-04
and C6-01
(0.000 - 65.000 Ω)
642
E4-06
(0326)
M2 Leak Inductance
Sets the voltage drop from motor 2 leakage inductance as a percentage of Motor Rated
Voltage when motor 2 operates at the rated frequency and rated current.
Determined by o2-04,
C6-01
(0.0 - 60.0%)
642
E4-07
(0343)
M2 Satur Coeff 1
Sets the motor 2 iron-core saturation coefficient at 50% of the magnetic flux.
0.50
(0.00 - 0.50)
643
E4-08
(0344)
M2 Satur Coeff 2
Sets the motor 2 iron-core saturation coefficient at 75% of the magnetic flux.
0.75
(E4-07 - 0.75)
643
E4-09
(033F)
Expert
M2 Mech Loss
Sets the mechanical loss of motor 2. Motor rated power (kW) is 100%. Usually it is not
necessary to change this setting.
0.0%
(0.0 - 10.0%)
643
E4-10
(0340)
M2 Iron Loss
Sets the motor iron loss for motor 2.
Determined by o2-04
and C6-01
(0 - 65535 W)
643
E4-11
(0327)
M2 Rated Power (kW)
Sets the motor rated power in the units from o1-58 [Mot Capacity Unit].
Determined by o2-04
and C6-01
(0.00 - 650.00 kW)
643
◆ E5: PM MOTOR SETTINGS
No.
(Hex.)
Name Description
Default
(Range)
Ref.
E5-01
(0329)
PM Mot Code Selection
Sets the motor code for Yaskawa PM motors. The drive uses the motor code to set some
parameters to their correct settings automatically.
Determined by A1-02,
o2-04, and C6-01
(0000 - FFFF)
644
E5-02
(032A)
PM Mot Rated Power
(kW)
Sets the PM motor rated output in the units from o1-58 [Mot Capacity Unit].
Determined by E5-01
(0.10 - 650.00 kW)
644
E5-03
(032B)
PM Mot Rated Current
(FLA)
Sets the PM motor rated current (FLA).
Determined by E5-01
(10% to 200% of the
drive rated current)
216
