Q2 Q2A User Manual

11.15 U: MONITORS
500 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
No.
(Hex.)
Name Description MFAO Signal Level Ref.
U6-25
(006B)
Expert
ASR Output Level Shows the primary delay filter input value of the ASR (speed control loop).
Unit: 0.01%
10 V: Motor secondary
rated current (-10 V to
+10 V)
-
U6-26
(006C)
Expert
Feed Fwd Cont Output Shows the Feed Forward control output.
Unit: 0.01%
10 V: Motor secondary
rated current (-10 V to
+10 V)
-
U6-27
(006D)
Expert
FF Estimate SPD Shows the feed forward estimated speed.
Unit: 0.01%
10 V = Maximum
frequency
(-10 V to +10 V)
-
U6-31
(007B)
Trq Detect Monitor Monitors the torque reference or the output current after applying the filter set to L6-07
[Trq Detect Filter Time].
Unit: 0.1%
10 V:100% -
U6-36
(0720)
Expert
Comm Err n-Host Shows the number of inter-CPU communication errors. De-energizing the drive sets this
number to 0.
No signal output
available
-
U6-37
(0721)
Expert
Comm Err n-Sensor Shows the number of inter-CPU communication errors. De-energizing the drive sets this
number to 0.
No signal output
available
-
U6-48
(072E)
Expert
ASIC Comm Errors Counts the number of inter-ASIC communication errors detected by the ASIC. This
count is reset to 0 when the power to the drive is turned off.
No signal output
available
-
U6-57
(07C4)
PoleDis IdDifVal Shows the change from the integrated current when finding the polarity.
Unit: 1
Note:
If the change from the integrated current is less than 819, increase n8-84 [Polarity
Det Current]. U6-57 = 8192 is equivalent to the motor rated current.
No signal output
available
-
U6-80 to U6-83
(07B0 to 07B3)
OPT IP ADR1 to 4 Shows the currently available local IP Address.
• U6-80: 1st octet
• U6-81: 2nd octet
• U6-82: 3rd octet
• U6-83: 4th octet
No signal output
available
-
U6-84 to U6-87
(07B4 to 07B7)
Online Subnet 1 to 4 Shows the currently available subnet mask.
• U6-84: 1st octet
• U6-85: 2nd octet
• U6-86: 3rd octet
• U6-87: 4th octet
No signal output
available
-
U6-88 to U6-91
(07B8, 07B9,
07F0, 07F1)
Online Gateway 1 to 4 Shows the currently available gateway address.
• U6-88: 1st octet
• U6-89: 2nd octet
• U6-90: 3rd octet
• U6-91: 4th octet
No signal output
available
-
U6-92
(07F2)
Online Speed Shows the currently available communications speed.
10: 10 Mbps
100: 100 Mbps
No signal output
available
-
U6-93
(07F3)
Online Duplex Shows the currently available Duplex setting. No signal output
available
-
U6-98
(07F8)
First Fault Shows the contents of the most recent communication options fault (DeviceNet,
Modbus TCP/IP, EtherNet/IP).
No signal output
available
-
U6-99
(07F9)
Current Fault Shows the contents of current fault from communication options (DeviceNet, Modbus
TCP/IP, EtherNet/IP).
No signal output
available
-
◆ U8: Q2PACK MONITORS
No.
(Hex.)
Name Description MFAO Signal Level Ref.
U8-01 to U8-10
(1950 - 1959)
Q2pack Mon 1 to 10 Shows Q2pack Monitors 1 to 10.
Unit: 0.01%
10 V = 100% -
U8-11 to U8-13
(195A - 195C)
Q2pack Ver 1 to 3 Shows Q2pack Versions 1 to 3. No signal output
available
-
U8-18
(1961)
Q2pack Base Platform Shows the Q2pack platform version. No signal output
available
-
