11.16 A1-02 [Control Method] Dependent Parameters
502 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
11.16 A1-02 [Control Method] Dependent Parameters
The values for the parameters in these tables depend on the values for parameter A1-02 [Control Method].
Changing the setting for A1-02 [Control Method] will change the default settings.
◆ Induction Motor Control Methods
Parameter Setting Range Unit
Control Method
V/f Control
(0)
PG V/f Control
(1)
OLVector
(2)
CLVector
(3)
Adv OLVector
(4)
b2-01 ZSpd/DCI Threshold 0.0 - 10.0 0.1 Hz 0.5 0.5 0.5 0.5 0.5
b2-04 DCInj Time@Stop 0.00 - 10.00 0.01 s 0.50 0.50 0.50 0.50 0.50
b3-01 SpSrch@Start Selection 0 - 1 1 0 1 0 1 0
b3-14 Speed Bi-Directional Search 0 - 1 1 1 0 1 1 1
b5-15 Sleep Start Level 0.0 - 400.0 0.1 Hz 0.0 0.0 0.0 0.0 0.0
b6-01 Dwell Ref.@Start 0.0 - 400.0 0.1 Hz 0.0 0.0 0.0 0.0 0.0
b6-03 Dwell Ref@Stop 0.0 - 400.0 0.1 Hz 0.0 0.0 0.0 0.0 0.0
b8-02 eSave Ctrl Gain 0.0 - 10.0 0.1 - - 0.7 1.0 1.0
b8-03 eSave Filter Time 0.00 - 10.00 0.01 s - - 0.50
*1
0.01
*1
0.01
*1
C1-11 Ac/Dec Switch Frequency 0.0 - 400.0 0.1 Hz 0.0 0.0 0.0 0.0 0.0
C2-01 Jerk@Start of Accel 0.00 - 10.00 0.01 s 0.20 0.20 0.20 0.20 0.20
C3-01 Slip Comp Gain 0.0 - 2.5 0.1 0.0 - 1.0 1.0 0.1
C3-02 Slip Comp Delay Time 0 - 10000 1 ms 2000 - 200 - -
C4-01 Trq Comp Gain 0.00 - 2.50 0.01 1.00 1.00 1.00 - -
C4-02 Trq Comp Delay Time 0 - 10000 1 ms 200
*2
200
*2
20 - -
C5-01 ASR PGain 1 0.00 - 300.00 0.01 - 0.20 - 20.00 10.00
C5-02 ASR ITime 1 0.000 - 60.000 0.001 s - 0.200 - 0.500 0.500
C5-03 ASR PGain 2 0.00 - 300.00 0.01 - 0.02 - 20.00 10.00
C5-04 ASR ITime 2 0.000 - 10.000 0.001 s - 0.050 - 0.500 0.500
C5-06 ASR Delay Time 0.000 - 0.500 0.001 s - - - 0.004 0.004
C5-07 ASR Gain Switch Frequency 0.0 - 400.0 0.1 Hz 0.0 0.0 0.0 0.0 0.0
C6-02 Carrier Frequency Selection 1 - F 1 1
*3
1
*3
1
*3
1 1
d3-01 Jump Frequency 1 0.0 - 400.0 0.1 Hz 0.0 0.0 0.0 0.0 0.0
d3-02 Jump Frequency 2 0.0 - 400.0 0.1 Hz 0.0 0.0 0.0 0.0 0.0
d3-03 Jump Frequency 3 0.0 - 400.0 0.1 Hz 0.0 0.0 0.0 0.0 0.0
d3-04 Jump Frequency Width 0.0 - 20.0 0.1 Hz 1.0 1.0 1.0 1.0 1.0
d5-02 Torque Ref Delay Time 0 - 1000 1 ms - - - 0 0
E1-04 Max Output Frequency 40.0 - 400.0
*3 *4
0.1 Hz 60.0
*5
60.0
*5
60.0 60.0 60.0
E1-05 Max Output Voltage 0.0 - 255.0
*6
0.1 V 200.0
*5
200.0
*5
200.0 200.0 200.0
E1-06 Base Frequency 0.0 - 400.0
*4
0.1 Hz 60.0
*5
60.0
*5
60.0 60.0 60.0
E1-07 Mid A Frequency 0.0 - 400.0
*4
0.1 Hz 3.0
*5
3.0
*5
3.0 0.0 3.0
E1-08 Mid AVoltage 0.0 - 255.0
*6
0.1 V 15.0
*5
15.0
*5
11.0 0.0 10.0
E1-09 Min Output Frequency 0.0 - 400.0
*4
0.1 Hz 1.5
*5
1.5
*5
0.5 0.0 0.6
E1-10 Min Output Voltage 0.0 - 255.0
*6
0.1 V 9.0
*5
9.0
*5
2.0 0.0 2.0
F1-01 Enc1 Pulse Count (PPR) 0 - 60000 1 ppr 600 600 600 600 600
F1-05 Enc1 Rotat Selection 0 - 1 1 0 0 0 0 0
F1-09 Overspeed Delay Time 0.0 - 2.0 0.1 s - 1.0 - 0.0 0.1
H4-20 An.Pwr Mon 100% Level 0.00 - 650.00 0.01
Default value of
E2-11
Default value of
E2-11
Determined by
E2-11
Determined by
E2-11
Determined by
E2-11
