12.10 o: KEYPAD
832 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
■ o1-51 Trend Plot Time Scale Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-51
(11CB)
RUN
Trend Plot Time Scale
Setting
Sets the time scale (horizontal axis) to display the trend plot. When you change this setting, the
drive automatically adjusts the data sampling time. This parameter is only available with an LCD
keypad.
5 s
(1 - 3600 s)
■ o1-55 AnGauge Area Selection
No.
(Hex.)
Name Description
Default
(Range)
o1-55
(11EE)
RUN
AnGauge Area Selection
Sets the range used to display the monitor set in o1-24 [Cust.Monitor 1] as an analog gauge. This
parameter is only available with an LCD keypad.
1
(0, 1)
0 : + - Area (- o1-56 - o1-56 )
1 : + Area (0 - o1-56 )
■ o1-56 AnGauge Area Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-56
(11EF)
RUN
AnGauge Area Setting
Sets the value used to display the monitor set in o1-24 [Cust.Monitor 1] as an analog meter. This
parameter is only available with an LCD keypad.
100.0%
(0.0 - 100.0%)
■ o1-58 Mot Capacity Unit
No.
(Hex.)
Name Description
Default
(Range)
o1-58
(3125)
Mot Capacity Unit
Sets the setting unit for parameters that set the motor rated power.
0
(0, 1)
The drive shows these parameter values in the set units:
• E2-11 [Motor Rated Power (kW)]
• E4-11 [Mid B Frequency]
• E5-02 [PM Mot Rated Power (kW)]
• E9-07 [Motor Rated Power (kW)]
• T1-02 [Motor Rated Power]
• T2-04 [PMMot Rated Power]
• T4-08 [Motor Rated Capacity]
0 : kW
Shows the motor output in kW units.
1 : HP
Shows the motor output in HP units.
◆ o2: KEYPAD OPERATION
■ o2-01 LO/RE Key Selection of Function
No.
(Hex.)
Name Description
Default
(Range)
o2-01
(0505)
LO/RE Key Selection of
Function
Sets the function that lets the drive switch between LOCAL and REMOTE Modes using the
button.
1
(0, 1)
0 : Disabled
You cannot use to switch between LOCAL and REMOTE Modes.
1 : Enabled
To Next Page
