Parameter List
11
11.7 F: OPTIONS
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 445
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F6-63
(03DE)
DNet Network MAC ID
Sets the function to see the actual DeviceNet MAC address using the keypad. This
parameter functions as a monitor only.
0
(0 - 63)
679
F6-64 to F6-67
(03DF - 03E2)
DynOut.Ass109 P1 to P4
Sets Configurable Outputs 1 to 4 written to the Modbus register.
0000h
(0000h - FFFFh)
679
F6-68 to F6-71
(03E3, 03E4,
03C7, and
03C8)
DynIn.Ass159 P1 to 4
Sets Configurable Inputs 1 to 4 written to the Modbus register.
0000h
(0000h - FFFFh)
679
F6-72
(081B)
PowerLink Address
Sets the node ID for PowerLink communication.
Note:
Set a node address that is unique. Do not set this parameter to a value of 0.
0
(0 - 255)
679
◆ F7: ETHERNET
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F7-01
(03E5)
IP Address 1
Sets the first octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Addr Mode@Startup = Static]:
• Use parameters F7-01 to F7-04 [IP Address 1 to IP Address 4] to set the IP
Address. Be sure to set a different IP address for each drive on the network.
• Also set parameters F7-01 to F7-12.
192
(0 - 255)
679
F7-02
(03E6)
IP Address 2
Sets the second octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Addr Mode@Startup = Static]:
• Use parameters F7-01 to F7-04 [IP Address 1 to IP Address 4] to set the IP
Address. Be sure to set a different IP address for each drive on the network.
• Also set parameters F7-01 to F7-12.
168
(0 - 255)
679
F7-03
(03E7)
IP Address 3
Sets the third octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Addr Mode@Startup = Static]:
• Use parameters F7-01 to F7-04 [IP Address 1 to IP Address 4] to set the IP
Address. Be sure to set a different IP address for each drive on the network.
• Also set parameters F7-01 to F7-12.
1
(0 - 255)
680
F7-04
(03E8)
IP Address 4
Sets the fourth octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Addr Mode@Startup = Static]:
• Use parameters F7-01 to F7-04 [IP Address 1 to IP Address 4] to set the IP
Address. Be sure to set a different IP address for each drive on the network.
• Also set parameters F7-01 to F7-12.
20
(0 - 255)
680
F7-05
(03E9)
Subnet Mask 1
Sets the first octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
255
(0 - 255)
680
F7-06
(03EA)
Subnet Mask 2
Sets the second octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
255
(0 - 255)
680
F7-07
(03EB)
Subnet Mask 3
Sets the third octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
255
(0 - 255)
680
F7-08
(03EC)
Subnet Mask 4
Sets the fourth octet of the subnet mask of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
0
(0 - 255)
680
