11.7 F: OPTIONS
444 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F6-46
(02FC)
BACnet BaudRate
Sets the BACnet communications speed.
1 : 1200 bps
2 : 2400 bps
3 : 4800 bps
4 : 9600 bps
5 : 19.2 kbps
6 : 38.4 kbps
7 : 57.6 kbps
8 : 76.8 kbps
9 : 115.2 kbps
3
(0 - 8)
676
F6-47
(02FD)
BACNet Rx-Tx Wait
Time
Sets the wait time for the drive to receive and send BACnet communication.
5 ms
(5 - 65 ms)
677
F6-48
(02FE)
BACnet DevOb Id0
Sets the last word of BACnet communication addresses.
0
(0 - FFFF)
677
F6-49
(02FF)
BACnet DevOb Id1
Sets the last word of BACnet communication addresses.
0
(0 - 3F)
677
F6-50
(03C1)
DNet MAC Address
Sets the MAC address for DeviceNet communication. Restart the drive after you change
this setting.
Note:
Be sure to set a MAC address that is different than all other node addresses. Do not
set this parameter to 0. Incorrect parameter settings will cause AEr [Station Address
Setting Error] errors and the MS LED on the option will flash.
0
(0 - 64)
677
F6-51
(03C2)
DNet Baud Rate
Sets the DeviceNet communications speed. Restart the drive after you change this
setting.
0 : 125 kbps
1 : 250 kbps
2 : 500 kbps
3 : Adjustable from Network
4 : Detect Automatically
0
(0 - 4)
677
F6-52
(03C3)
DNet PCA Setting
Sets the format of data that the DeviceNet communication master sends to the drive.
21
(0 - 255)
677
F6-53
(03C4)
DNet PPA Setting
Sets the format of data that the drive sends to the DeviceNet communication master.
71
(0 - 255)
677
F6-54
(03C5)
DNet Idle Fault
Detection
Sets the function to detect EF0 [Option Card External Fault] when the drive does not
receive data from the DeviceNet master.
0 : Enabled
1 : Disabled, No Fault Detection
2 : Vendor Specific
3 : RUN Forward
4 : RUN Reverse
0
(0 - 4)
678
F6-55
(03C6)
DNet Baud Monitor
Sets the function to see the actual DeviceNet communications speed using the keypad.
This parameter functions as a monitor only.
0 : 125 kbps
1 : 250 kbps
2 : 500 kbps
0
(0 - 2)
678
F6-56
(03D7)
DNet Speed Scale Factor
Sets the speed scale for DeviceNet communication.
0
(-15 - +15)
678
F6-57
(03D8)
DNet Current Scale
Factor
Sets the current scale of the DeviceNet communication master.
0
(-15 - +15)
678
F6-58
(03D9)
DNet Torque Scale
Factor
Sets the torque scale of the DeviceNet communication master.
0
(-15 - +15)
678
F6-59
(03DA)
DNet Power Scaling
Sets the power scale of the DeviceNet communication master.
0
(-15 - +15)
678
F6-60
(03DB)
DNet Voltage Scale
Sets the voltage scale of the DeviceNet communication master.
0
(-15 - +15)
678
F6-61
(03DC)
DNet Time Scale
Sets the time scale of the DeviceNet communication master.
0
(-15 - +15)
679
F6-62
(03DD)
DNet Heartbeat Interval
Sets the heartbeat for DeviceNet communication. Set this parameter to 0 to disable the
heartbeat function.
0
(0 - 10)
679
