Parameter Details
12
12.6 F: OPTIONS
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 677
■ F6-47 BACNet Rx-Tx Wait Time
No.
(Hex.)
Name Description
Default
(Range)
F6-47
(02FD)
BACNet Rx-Tx Wait Time
Sets the wait time for the drive to receive and send BACnet communication.
5 ms
(5 - 65 ms)
■ F6-48 BACnet DevOb Id0
No.
(Hex.)
Name Description
Default
(Range)
F6-48
(02FE)
BACnet DevOb Id0
Sets the last word of BACnet communication addresses.
0
(0 - FFFF)
■ F6-49 BACnet DevOb Id1
No.
(Hex.)
Name Description
Default
(Range)
F6-49
(02FF)
BACnet DevOb Id1
Sets the last word of BACnet communication addresses.
0
(0 - 3F)
■ F6-50 DNet MAC Address
No.
(Hex.)
Name Description
Default
(Range)
F6-50
(03C1)
DNet MAC Address
Sets the MAC address for DeviceNet communication. Restart the drive after you change this
setting.
0
(0 - 64)
Note:
Be sure to set a MAC address that is different than all other node addresses. Do not set this parameter to 0. Incorrect parameter settings
will cause AEr [Station Address Setting Error] errors and the MS LED on the option will flash.
■ F6-51 DNet Baud Rate
No.
(Hex.)
Name Description
Default
(Range)
F6-51
(03C2)
DNet Baud Rate
Sets the DeviceNet communications speed. Restart the drive after you change this setting.
0
(0 - 4)
0 : 125 kbps
1 : 250 kbps
2 : 500 kbps
3 : Adjustable from Network
The controller sets the communications speed.
4 : Detect Automatically
The drive detects the network communication speed and automatically adjusts the communications speed.
■ F6-52 DNet PCA Setting
No.
(Hex.)
Name Description
Default
(Range)
F6-52
(03C3)
DNet PCA Setting
Sets the format of data that the DeviceNet communication master sends to the drive.
21
(0 - 255)
Note:
If F6-52 [DNet PCA Setting] and F6-53 [DNet PPA Setting] are not correct, the value is reset to default.
■ F6-53 DNet PPA Setting
No.
(Hex.)
Name Description
Default
(Range)
F6-53
(03C4)
DNet PPA Setting
Sets the format of data that the drive sends to the DeviceNet communication master.
71
(0 - 255)
