12.7 H: TERMINALS
744 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
■ 32: Q2pack AI3
Setting Function Description
32 Q2pack AI3
Use with Q2pack. Refer to the Q2pack online manual for more information.
■ 33: Q2pack AI4
Setting Function Description
33 Q2pack AI4
Use with Q2pack. Refer to the Q2pack online manual for more information.
■ 34: Q2pack AI5
Setting Function Description
34 Q2pack AI5
Use with Q2pack. Refer to the Q2pack online manual for more information.
■ 35: Q2pack AI6
Setting Function Description
35 Q2pack AI6
Use with Q2pack. Refer to the Q2pack online manual for more information.
◆ H4: ANALOG OUTPUTS
H4 parameters set the drive analog monitors. These parameters select monitor parameters, adjust gain and bias,
and select output signal levels.
■ Calibrate Meters Connected to MFAO Terminals AO1 and AO2
You can use H4-02, H4-03, H4-05, and H4-06 [AO1 An.Out Gain, AO1 An.Out Bias, AO2 An.Out Gain, and AO2
An.Out Bias] to calibrate meters connected to terminals AO1 and AO2.
No. Name Setting Range Default Setting
H4-02 AO1 An.Out Gain -999.9 - 999.9% 100.0%
H4-03 AO1 An.Out Bias -999.9 - 999.9% 0.0%
H4-05 AO2 An.Out Gain -999.9 - 999.9% 50.0%
H4-06 AO2 An.Out Bias -999.9 - 999.9% 0.0%
H4-07 AO1 Signal Level Select
0: 0-10 VDC
1: -10 +10 VDC
2: 4-20 mA
0
H4-08 AO2 Signal Level Select
0: 0-10 VDC
1: -10 +10 VDC
2: 4-20 mA
0
Figure 12.107 shows the gain and bias.
